Metal Packaging - Pail
Equipped with fully automated Sargiani pail lines that were installed with Soudronic welders, we are capable of producing high quality pails (triple seamed) for capacities ranging from 10 to 25 litres.
As part of our commitment to quality, we have also installed Wilcomat online leakage detector that conducts 100% check for all manufactered pails. It detects leakages for pin holes and defects up to 0.3mm.
We offer two types of pails:
- Open top - The capacity ranges from 10 litres to 25 litres, which include normal taper and conical pail.
- Tight head - The capacity ranges from 18 litres to 25 litres, seamed with various closures such as royal cap, screw cap, flexspout, flange and plug.
a. Open Top
Body Thickness (mm): from 0.28 ± 0.03 to 0.43 ± 0.04
Bottom Thickness (mm) : from 0.30 ± 0.03 to 0.43 ± 0.04
Capacity | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | H (mm) |
---|---|---|---|---|---|---|---|
10 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 271 ± 1 |
14 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 275 ± 1 |
15 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 274 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 287 ± 1 |
16 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 274 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 300 ± 1 |
16 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 300 ± 1 |
18 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 274 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 329 ± 1 |
18 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 329 ± 1 |
18 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 30 ± 1 | 62 ± 3 | 113 ± 1 | 329 ± 1 |
20 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 274 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 365 ± 1 |
20 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 90 ± 1 | 365 ± 1 |
20 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 110 ± 1 | 365 ± 1 |
21.5 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 100 ± 1 | 376 ± 1 |
25 Litre | Ø 299 ± 1 | Ø 285 ± 1 | Ø 276 ± 1 | 35 ± 1 | 62 ± 3 | 110 ± 1 | 445 ± 1 |
b. Tight Head
Body Thickness (mm): 0.38 ± 0.04
Bottom Thickness (mm) : 0.38 ± 0.04
Top Thickness (mm) : 0.38 ± 0.04
Capacity | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | H (mm) | Closure | |||
---|---|---|---|---|---|---|---|---|---|---|
Royal Cap | Screw Cap | Flexspout | Flange & Plug | |||||||
18 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
45 ± 5 |
329 ± 1 |
✔ |
✔ |
✔ |
|
18 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
60 ± 5 |
329 ± 1 |
✔ |
|||
20 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
45 ± 5 |
371 ± 1 |
✔ |
✔ |
✔ |
|
20 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
60 ± 5 |
371 ± 1 |
✔ |
|||
25 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
45 ± 5 |
450 ± 1 |
✔ |
✔ |
✔ |
|
25 Litre |
Ø 275 ± 1 |
Ø 290 ± 1 |
35 ± 1 |
35 ± 1 |
60 ± 5 |
450 ± 1 |
✔ |
